| qj180 mineral truck |
| item no : qj5820d1x-md |
| qj180 mineral truck specifications | | no. | item | modeal/specifications | remarks | | 1 | engine | yn4102,90hp | air brake | | 2 | gearbox | 145 gearbox rear located additional gearbox | | | 3 | front axle | 1069 axle (short track) , 4tones | ratio:6.17 | | 4 | rear axle | | 5 | cabin | simple cabin | | | 6 | front tire | 7.00-16×6 | | | 7 | rear tire | | 8 | front leaf srping | qj131-3jc01 | | | 9 | rear leaf spring | qj131（13）-1 | | | 10 | sub-leaf spring | | 11 | steering gear | cj8067c | | | 12 | hydraulic system | 3tg1-90×330, two pcs | no sub-frame | | 13 | battery | 80ah,12v | free maintenance type | | 14 | frame | three layers, thickness: 8 4 4mm | | | 15 | sub-frame | without | | | 16 | overall size，mm | 4350x1830x1600 | | | 17 | bucket,mm | 2900×1600×600 | thickness: bottom 10mm, side 5mm | | 18 | wheel track,mm | frt:1560；rr:1350 | | | 19 | wheelbase,mm | 2390 | | | 20 | kerb weight | 3220kg | | | 21 | bucket weight | 920kg |  |
|
| buy contact views : 5136 2016-9-18 |
| |
|
