| rh driving dump truck |
| item no : qj5820cd3 |
| description: |
|
| | qinji branddump truck is a light-duty truck applying to medium and short distance transportation in urban and rural area. it features with compact structure, reliable performance, flexible steering, easy operation, large capacity and great grade-ability. according to users’ different requirements, a vacuum assisted brake or air brake, an additional gearbox or twin-gearbox, common steering or power steering, air conditioner could be optional. | |
|
|
| | item | specifications | remarks | | cabin | type 1043, long-headed, single seat-row | right-hand driving | | engine | yn4100qb, yn4102qb, yc4105, yc4108 optional | 140 clutch housing, with ac bracket | | gearbox | 140 130 gearbox | (5 1)×4 | | air conditioner | optional | | | frame | revited with 2 layers of steel plate, with height of 230mm | thinckness:8 5mm, material 09sivl | | axle | frt: 2050 or 2060 driving axle | | | loading: 5t, 7t, 9t, air brake | | | hydraulic cylinder | two cylinder:φ110×400, single cylinderφ160×600, φ180×600 optional | two cylinder or single armcrank cylinder optional | | steering gear | 3401jac-010, power steering | | | clutch | type 140, air power assisted | | | brake | air brake, with dryer | | | parking brake | exhaust brake | | | leaf spring | type 140 improved | | | battery | 12v, 80ah, two | | | loading space | 3600mm×2200mm×700mm | to be extended as per requirements | | propeller shaft | 153 | | | tire | 8.25-16×2/8.25-16×4 | | | truck weight (kg) | 3940 | | | wheelbase(mm) | 3730 | | | frt/rr track(mm) | 1650/1650 | | | frt/rr overhang (mm) | 940/1480 | | | min. ground clearance (mm) | ≥200 | | | overall size l×w×h | 6150mm×2300mm×2500mm | |
|
| buy contact views : 6708 2014-5-29 |
| |
|
