| dump tractor qj5820cd4 |
| item no : qj5820cd4 |
 description: qinji brand dump truck is a light-duty truck applying to medium and short distance transportation in urban and rural area. it features with compactstructure, reliable performance, flexible steering, easy operation, large capacity and great grade-ability. according to users’ different requirements, a vacuum assisted brake or air brake, an additional gearbox or twin-gearbox, common steering or power steering, air conditioner could be optional.
main technical specifications: item | specifications | remarks | cabin | type 1043, long-headed, single seat-row |
| engine | yn4100qb, yn4102qb, yc4105, yc4108 optional | 140 clutch housing, with ac bracket | gearbox | 140 130 gearbox | (5 1)×4 | air conditioner | optional |
| frame | revited with 2 layers of steel plate, with height of 230mm | thinckness:8 5mm, material 09sivl | axle | loading: 5t, 7t, 9t, air brake |
| hydraulic cylinder | two cylinder:φ110×400，single cylinderφ160×600，φ180×600 optional | two cylinder or single armcrank cylinder optional | steering gear | 3401jac-010, power steering |
| clutch | type 140, air power assisted |
| brake | air brake, with dryer |
| parking brake | exhaust brake |
| leaf spring | type 140 improved |
| battery | 12v，80ah, two |
| loading space | 3600mm×2200mm×700mm | to be extended as per requirements | propeller shaft | 153 |
| tire | 8.25-16×2/8.25-16×4 |
| truck weight（kg） | 3940 |
| wheelbase（mm） | 3730 |
| frt/rr track(mm) | 1650/1650 |
| frt/rr overhang（mm） | 940/1480 |
| min. ground clearance（mm） | ≥200 |
| overall size l×w×h | 6150mm×2300mm×2500mm |
|
|
