| 4wd farm dump truck - 5t |
| item no : qj5830cd2. |
| qj5830cd2 farm dump tractor - 4wd 5t | | 1.main specifications: | | weight | kerb weight (kg) | 4300 | | payload (kg) | 5000 | | gross weight (kg) | 93000 | | size | wheelbase (mm) | 3600 | | wheel track | front (mm) | 1650 | | rear (mm) | 1650 | | overall size (mm) | 5900×2180×2530 | | overhang, frt/rr（mm） | / | | min. ground clearance（mm） | ≥200 | | 2. main compositions: | | item | description | remarks | | cabin | long headed signle seat-row, easy type | with windshiel and wiper | | engine | yn4102,diesel | air brake,with 140 clutch | | gearbox | typed 145 with front-located sub-gearbox | direct operaton (by rod) | | power transfer | model hp5t | | | frame | 2 layers of steel plate riveted 5 4mm, with height 200mm | | | axle | frt:wtzq2068s (double cross-shaft joint) | drum brake | | rr: wth1080 | | power steering | model 3401qjy-010 | rh located, power steering | | hydraulic cylinder | e125×500 | single cylinder,crankarm type | | brake system | air brake | | | clutch system | 140 clutch | mechanic type | | leaf spring | 131 improved type | | | battery | 12v，105ah, 2 pcs | | | bucket | 3200×2100×(600 300)mm | | | tire | 8.25-16×7 | | | hydraulic winch | optional, for self-saving |
|
| buy contact views : 3616 2014-11-8 |
| |
|
