- description:
this type of 4wd dump truck is specially designed for transportation of palm fruits in southeast asia countries, also could be used for transporting wood, cassava, sand and stone, etc.
- main features:
- - four wheel driving truck (4wd) design
- - lh or rh steering
- - dump truck, single crankarm cylinder or 2-cylinder lifting hydraulic cylinder
- - good for hilly and muddy area, with off-road condition
- - self-saving system- hydraulic winch
- - open type of cabin
- main specifications:
- - rated payload(kg): 2000-3000
- - truck weight(kg): 3500
- - overall size(mm): 5935*2000*2335
- - engine: diesel, yc490/yc495, 65/76hp
- - gearbox: (5 1) *2
- - 4x4 transmission: qj60k
- - wheelbase(mm): 3465
- - wheel track(mm) - front: 1500; rear: 1530
- - front/rear overhang(mm): 1265/1205
- - min. ground clearance(mm): ≥200
- - max. speed (km/h): 66
- - min. turning radius (m): ≤7.5
- - oil consumption (l/t.100km): 2.8 hydraulic winch 20000lbs:
front driving axle:
engineering tyre:
carrying palm fruits:
carrying wood:
|
